New, to my collection.

[Alfonso]

Bbbb shotgun attachment


Materials used:
4x coupler
4X 1/2" pvc, 7" in legnth
ABS cap
ABS funnel thing (for lack of a better name)
ABS pipe to adhere the other two abs parts
1/2" threaded pvc bushing
1/2" nipple adapter

and yes, it works. well.




I have single pvc and cpvc barrel attachments but I didn't post them because it's nothing out of the ordinary.

Edited by Alfonso, 25 July 2008 - 08:42 PM.

[bogboogalars]

What did you make that out of?

[oodalumps]

Picked up a Ratchet Blast at a garage sale for 75 cents. Pulled the pegs out and replaced the barrels with 4" of petg and 2" of 17/32 brass nested inside. Gets 40-50' flat. With more mods it should do better, but I'll need to reinforce it first. It seemed like a kickass side arm, but it didn't fit in my pockets. So I made a ghetto holster out of a Dart Tag vest and e-tape. Fits like a glove.

Edited by oodalumps, 26 July 2008 - 08:18 PM.

[Mxer4life369]

This is my Sand Camo Color Firefly.

And it's CPVC turret


Well, theres my paintjob.

[Shrub]

Ice's BBB



My BBBB

http://i307.photobuc...er/DSCN0125.jpg

[Philote]

My new sidearm, the scout has OfAll's mod and the SSPB's are stock.

[Blacksunshine]

Holy shit that BBB looks likes its been abused, video taped while being diddled then made to watch the video while it was diddled again.




A pic of my latest.




Mods (takes deep breath)
replaced barrel with PETG nested 1/2" PVC Flared at exit end for ease of dart loading. 4" barrel
plunger tube sealed
Air restrictors removed and A/R spring holder drilled out
plunger reinforcement w/ metal washer
double o ring
Silicone lubed
Handyman 9713(whatever) 24lb spring
catch and trigger springs replaced with stronger
body of gun reinforced with epoxy putty (in front of plunger tube and screws that hold plunger tube
plunger rod also received same treatment for extra strength
Handle weighted to offset heavier front end gun balances on 1 finger
Minimized and hand painted.

Edited by Blacksunshine, 30 July 2008 - 12:22 PM.

[ice]

My latest





Mods, fully CPVCed
Reinforced plunger head
Foam ring for silencing in plunger chamber
Fully lubed
Cut shell
Replaced catch and trigger springs
New priming handle conected to CPVC coupler (no boltsled)
Plexy glass over area that accepts the clip
Hand painted
+
Integration: crossfire
CPVCed
Removed AR's
Cut dart holder
Hand painted

My new primary

[El Karlos]

My first mod, a gutted NF with a double spring and a quick change cpvc barrel.



Gets about 45' flat and 70' angled.

Edited by El Karlos, 30 July 2008 - 07:06 PM.

[jerm78]

A few of my guns









A few more

[rork]

These are a couple of minimized, cpvc'd nite-finders. The top one has a 6-shot turret/flip breech thing, which works rather absurdly well. I think of it as a giant middle finger in the general direction of the wretched maverick.

[bobafan]

Here is my current baby.

ARs removed, better springs, wasted space removed, etc.. It also has a triple torch on the side for backup and a breech of my own design.
Paintjob to come.

Edited by bobafan, 04 August 2008 - 11:17 AM.

[VACC]

Deleting posts without original images is getting annoying. Deleting accounts will be easier.

Silent "word that you should know we fucking hate", my patience with you has run out. Disappear for a bit and learn the rules.

[Gears]

I'm not sure if I'm going to make Ice's war on Saturday, so I thought i may as well whip this together, just to be safe. It's a couplered BigBlast with a couplered AT2k integration. I still need to add the keyring trigger.

Edited by Gears, 05 August 2008 - 09:58 AM.

[ChiliPepperFender]

A little sneak peak of my project in the works.

[oodalumps]

Some of my springers weren't performing as well as I liked, so I finally got some CPVC to test that barrel material out. The results were way above expectations. The RazorBeast has the usual mods done do it with CPVC chains. The TTG is couplered with a bored out piece of PVC in front to make loading easier and a SS1 spring replacement; Also has quick reload barrels in the ammo holders. The Max Shot was surprisingly easy to mod, as the white stock barrel is the exact same size as CPVC (I didn't know that!), so I couplered it. All 3 of them get great ranges.


lol yugioh

Edited by oodalumps, 06 August 2008 - 08:22 PM.

[Mxer4life369]

Alright since everybody was harrassing me about my nf thread, I'm going to post here.

This is my NF. I painted it and coupler modded it. I posted a topic about what colors would look good with the orange, and it didnt work out. So I got to thinking, a blue and orange NF would be sick. So I did it. And I believe it does look sweet.
Here it is uncocked

Here it is "Cocked, Locked, and Ready to ROCK!"

Here is the gun with the barrel detached.

Here is a view of the business end of the gun. As you can see, I put some blue craft foam on the plunger to match the paintjob.

And this is what I see when I bust a cap in some fool's ass.


EDIT: Fuck, nobody says anything positive, I just got flamed for having too big of pics. WTF!

As you can see, I'm not TOTALLY done, because I still have to paint the laser casing, dart holders, and battery cover. But other than that this baby is DONE!

Edited by Mxer4life369, 07 August 2008 - 10:00 AM.

[joeyaglr444]

I suggest you resize those pics before an admin snatches the soul from your body.

[rork]

Updated with a true turret system. There's a writeup in the mods section.

[Aimless]

My BBBB's first paintjob. Has the standard mods done to it.

The trigger is reinforced with strips of cookie tin, it's held up to all the abuse so far.

The enamel paint started to wear through so I repainted it. Theres also quite a bit of clearcoat on it now.

I didn't repaint the trigger because the enamel paint seems to bond well with it.

[jerm78]

finally got my (Jet Hawks)roto rocket

[serpent sniper]

I finished another maverick. It's not steampunk this time!

Edited by serpent sniper, 11 August 2008 - 10:44 PM.

[trogdor65]

So here is my pump action shotgun that I got from a friend. When I first opened it up two screws in the very front of the gun, that hold the entire plunger assembly together, were both broken. So the silver part on the front is my new bolt/screw, I didn't make a new screw on the bottom part because it would affect the pump action charging grip. Anyways right now I'm working on doing some of Forsaken's mod, and I need some more brass so the barrel isn't finished. So watcha think?

Edited by trogdor65, 08 August 2008 - 04:13 PM.
