Wooden Crossbow Head

Out of ideas for crossbow head try this....

7 replies to this topic

#1 BustaDartInYOurAss

BustaDartInYOurAss

    Member

  • Members
  • 148 posts
  • Location:Commack, Long Island NY

Posted 17 September 2008 - 04:35 PM

My friend FERD'S Crossbow head was breaking off constantly and we have tried 4 differents heads and all of them failed except for this one.

Posted Image

Posted Image

I made this head using a 1 1/4 x 48 wooden dowel and cutting it down. Then I drilled a hole through the middle of the wood.I then drilled a hole through the middle of the pluger shaft.After that I used a srew, it doesnt matter what size.Then srewed it through both of the holes. After that we used liquid epoxy to hold in the screw.Then lube the head and cover the bottom in E tape, and there you go.A working crossbow head if yours is ever to fall off.

Edited by BustaDartInYOurAss, 17 September 2008 - 07:40 PM.

  • 0

#2 FERD

FERD

    Member

  • Members
  • 27 posts

Posted 17 September 2008 - 04:36 PM

It still works great............. :D
  • 0
Im not nice...................... I KICK BABIES

#3 BlackFox

BlackFox

    Member

  • Members
  • 286 posts
  • Location:Gorst, Washington

Posted 17 September 2008 - 04:51 PM

Very nice work. How are the ranges? I've done tons of work on the xbow plunger head and the biggest difficulty is the inward slant the plunger tube has, so a simple replacement didn't work for me. If it holds up well, I might do something like this when/if my solution fails.

Check it out! This was actually my second xbow repair.

EDIT: Wait- is that picture seriously the end result? Did you even put a wrap of etape or an O-ring on the plunger head to seal against the plunger tube?

Edited by BlackFox, 17 September 2008 - 04:54 PM.

  • 0
"Until we meet in the place where there is no darkness"
-George Orwell, 1984
-----------

Think that piece is beyond repair? Think again!

#4 mystefansdontflystraight

mystefansdontflystraight

    Member

  • Members
  • 1,176 posts
  • Location:Toronto, Canada

Posted 17 September 2008 - 04:53 PM

I would put some foam on it, but it looks good.
  • 0
QUOTE(Blacksunshine @ Dec 24 2009, 02:15 PM) View Post

QUOTE(white moonlight @ Dec 23 2009, 01:29 PM) View Post

It's just screaming to be rearloading...

I seen a movie about that once.



#5 FERD

FERD

    Member

  • Members
  • 27 posts

Posted 17 September 2008 - 05:28 PM

Very nice work. How are the ranges? I've done tons of work on the xbow plunger head and the biggest difficulty is the inward slant the plunger tube has, so a simple replacement didn't work for me. If it holds up well, I might do something like this when/if my solution fails.

Check it out! This was actually my second xbow repair.

EDIT: Wait- is that picture seriously the end result? Did you even put a wrap of etape or an O-ring on the plunger head to seal against the plunger tube?


The ranges are pretty good ther like 80 feet flat back loaded with a stefan. And yes that picture is the end reslut we didnt put any etape around it or an O-ring.
  • 0
Im not nice...................... I KICK BABIES

#6 BlackFox

BlackFox

    Member

  • Members
  • 286 posts
  • Location:Gorst, Washington

Posted 17 September 2008 - 05:48 PM

The ranges are pretty good ther like 80 feet flat back loaded with a stefan. And yes that picture is the end reslut we didnt put any etape around it or an O-ring.

Wow, I am shocked. Are you using bungies? That's amazing if you aren't.
  • 0
"Until we meet in the place where there is no darkness"
-George Orwell, 1984
-----------

Think that piece is beyond repair? Think again!

#7 BustaDartInYOurAss

BustaDartInYOurAss

    Member

  • Members
  • 148 posts
  • Location:Commack, Long Island NY

Posted 17 September 2008 - 05:54 PM

Nope, no bungies at all, Just a defender spring. And the reason i did not put any e tape or a o-ring is because the wood, with a bit of sanding fit very nicely. Top it all off with some lube and you have a beast

Edited by BustaDartInYOurAss, 17 September 2008 - 05:59 PM.

  • 0

#8 Mr BadWrench

Mr BadWrench

    Member

  • Members
  • 781 posts
  • Location:Bum Funk Ohio

Posted 17 September 2008 - 07:44 PM

Top it all off with some lube and you have a beast


thats gonna get added that hilarious quote to my signature, while playing with my butthole
